Ideal Commercial Boilers Condensing Range Covers All Bases

Ideal Commercial's Condensing Boiler range provides you with an almost unparalleled span of models and outputs. Featuring wall hung, floor standing, modular and pressure jet boilers with outputs from 30kW to 1450kW, there's an Ideal Commercial boiler suitable for most projects, many with FREE Commissioning.

The Condensing boiler range is made up of 5 models:

Evomax

  • Wall hung condensing boiler
  • Large range of outputs in market (30, 40, 60, 80, 100, 120 and 150 kW natural gas; 30, 40, 60 and 80kw LPG)
  • Robust & light aluminium silicon alloy heat exchanger
  • Up to 110% part load efficiency
  • High 5:1 turndown
  • Compact – one width & height for easy siting
  • Simple controls interface with large backlit display
  • 5 year parts and labour warranty (subject to terms and conditions)
  • NOx <40mg/kWh (Class 5) for all natural gas models for maximum BREEAM points
  • Comprehensive range of flue, fixing and control options
  • Frame and Header and Multiline Flue Kits available for cascades of up to 6 boilers
  • FREE COMMISSIONING

Imax Xtra

  • Floor standing condensing boiler available in 6 outputs (80, 120, 160, 200, 240 and 280kW)
  • Robust cast aluminium silicon alloy heat exchanger

  • In-built commissioning and fault diagnostics

  • Volt free contacts and BMS operation standard

  • Compact size - small footprint and fits through standard doorways

  • High 5:1 turndown

  • Up to 107.5% net efficiency (fully condensing)

  • Conventional or room sealed flue options

  • NOx <40mg/kWh (Class 5) for maximum BREEAM points

  • 2 year parts and labour warranty

  • FREE COMMISSIONING

Imax Xtra EL

  • Floor standing condensing boiler available in 10 outputs (320, 395, 475, 545, 620, 715, 790, 940, 1090 and 1240kW)
  • Simple control interface with large backlit display

  • Volt free contacts

  • 0-10V BMS operation standard

  • Robust aluminium silicon alloy heat exchanger

  • Suitable for single or multiple installations

  • Up to 109.8% part load at 30% output

  • NOx <40mg/kWh (Class 6) for maximum BREEAM points

  • ErP compliant (320 - 395kW)

  • Building Regulation Part L2 compliant (470 - 1240kW)

  • 2 year parts and labour warranty

  • FREE COMMISSIONING

Evomod

  • Floor standing modular condensing boiler.  Each module provides a maximum of 250kW and up to 4 can be combined for an output of 1MW
  • Modules up to 3 high stacking

  • Stainless steel heat exchanger

  • Up to 108.5% net efficiency (fully condensing)

  • Built in module diagnostics, sequencing and remote indication

  • Plain text display for fast and easy use

  • Single flue outlet, system, gas and electrical connections

  • Up to 20:1 turndown

  • Easy access for servicing

  • Minimum footprint with easy site handling and standard doorway access

  • NOx <40mg/kWh (Class 5) for maximum BREEAM points

  • Single boiler control for all module options

  • 2 year parts and labour warranty

  • FREE COMMISSIONING

Evojet

  • Condensing pressure jet boiler with up to 10 outputs and natural gas, LPG, oil and dual fuel models
  • Natural gas and LPG burner options: 150, 210, 270, 350, 450, 600, 800, 1000, 1250 and 1450kW
  • Oil burner options: 210, 270, 350, 450, 600, 800, 1000, 1250 and 1450kW
  • Dual Fuel burner options: 450, 600, 800, 1000, 1250 and 1450kW
  • Up to 109.3% part load efficiency

  • Dedicated low temp return

  • Stainless steel heat exchanger

  • Triple flue pass for high operating efficiencies

  • Natural gas/LPG burner options - modulating or high / low operation

  • ?Modulation via 0-10 volt BMS or RWF controller

08 June 2018


Click here to find out more about: Ideal Commercial Boilers
